FILPRO offers Magnetic Level Indicator to provide clear, high clarity indication of liquid level. Typically, Magnetic Level Indicator consists of three major components: Float Chamber, Float and Indicator System. Magnetic Level Indicator is principally designed as an alternative to glass level gauges. We offer Magnetic Level Indicator having top-bottom, top and side mounted construction with two types of indicator system i.e. Capsule and Bi-colour Rollers. Magnetic level indicators are tailor made to various types of construction and sizes.
Working Of Magnetic Level Indicator:
Magnetic Level Indicator operates on the principle of magnetic field coupling to provide fluid level information. Float chamber is typically constructed with a non-magnetic pipe having process connections that match to the vessel connections.
Float size and weight are determined by the process fluid, pressure, temperature and the specific gravity of the process fluid. Float contains magnets to provide 360o magnetic flux field.
Specifications:
Type: Magnetic Level Gauge
Mounting Orientation: Top Mounted, Side Mounted & Top – Bottom
Indicator System: Bi-colour Rotating Roller / Capsule
Housing for Indicator: For Bi-colour Roller – RAIL in Aluminium or SS Housing System For
Capsule – Heavy Walled Glass Tube in Aluminium / SS Housing
MOC of Indicator: ABS Plastic / SS
Float Chamber: Non-Magnetic Standard pipe
MOC of Float Chamber: SS 304, SS 316, SS 316L, PP, PVDF, Others on request
Float: SS 304, SS 316, SS 316L, PP, PVDF, Others on request
Scale: Aluminium / SS / Acrylic engraved in mm
Process Connection: Flanged in various sizes
Vent: 1⁄2” Plugged / 1⁄2” Needle Valve / 1⁄2” Ball Valve
Drain: 1⁄2” Plugged / 1⁄2” Needle Valve / 1⁄2” Ball Valve
Limit Switch Assembly: Snap Acting 1 SPDT Micro switch, 5A, 230 VAC or 24 VDC X 0.7A Reed Switch
Switch Housing: Aluminium Die Cast Weatherproof to IP – 65
Aluminium Die Cast Explosion proof suitable for Group IIA, IIB
Aluminium Die Cast Explosion proof suitable for Group IIC
Electrical Cable Entry: 3⁄4” ET (F)
Centre to Centre Distance: Bi-colour Rollers – up to 6000 mm, Capsule – up to 6000 mm
Max. Operating Pressure: 15 Kg/cm2 (others on request)
Performance:
Reliable for aggressive, combustible, toxic, high pressure and high temperature (up to 150°C) liquid storage tanks.
Side mounted magnetic level indicator most reliable and safe for a hazardous application like LPG, Oleum, Chlorosulfuric Acid, HNO2, and Solvents like benzene, Toluene alcohols.
Useful for Acid, Alkali, Solvent, Oils, Vegetable Oil.
