Filpro Sensors Pvt Ltd manufactures industrial Level Controller (Smart On) to automatically start & stop the pump.
For this tank has to be fitted with our Magnetic Float Switch or Cable Float Switch.
Liquid Level Controller (Smart On) provides LED Indication for Power ON, Relay ON (Motor ON), Tank High & Tank Low.
The controller has provision to select pump mode as Pump UP or Pump Down. In Pump UP mode, the pump starts at Low Level & Stops at High Level. Pump UP mode is used to fill the tank. In Pump DOWN mode, the pump starts at High Level & Stops at Low Level. Pump DOWN mode is used to empty the tank.
Specifications:
Input Supply: 230V AC
Sensor Input: From Magnetic Float Switch or Cable Float Switch
Output: 1NO contact rated for 230V AC, 5A
Mounting: Back panel 35mm din rail mounting
Mode: Pump UP ( Filling ) or PUMP Down ( Emptying)
Atex approved Float Level Transmitter :
Over All Length: 300mm to 5000mm
Input: 16V DC to 30V DC
Output: 4-20mA / 0-10V DC
Resolution: 5mm / 10mm
Enclosure: Cast Aluminium, IP66
Wetted parts: SS 304 / SS 316 / SS 316L / Titanium
Mounting: Flange / Thread / Tri clover
Accracy: +/- 0.5% FS
Approval: EX II 1G Ex ia IIB T4 Ga
EX II 2G Ex db IIB T4 Gb
Ligo fuel sensor for monitoring Diesel and Petrol level in vehicle fuel tanks and DG sets.
Highly accurate upto 99.5%
Available in length : 700mm, 1000mm and 1500mm upto 6000mm
Input: 9-37V DC
Output: 0-5V DC, 0-10V DC, RS 485, RS 232
Resolution: 12 bit
